Smart Thermostats Manufacturer
8929 RS485 modbus WIFI DC brushless Smart Thermostat with TUYA, Alexa & Google Assistant - 2 pipe 1ch Heating or cooling
8929 RS485 modbus WIFI DC brushless Smart Thermostat with TUYA, Alexa & Google Assistant - 2 pipe 1ch Heating or cooling
Regular price
$24.00 USD
Regular price
Sale price
$24.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
INTRODUCTION:
This 8929 WIFI cooling heating DC brushless Smart Thermostat is suitable for central air conditioning systems. This 8918 Fan Coil Thermostat features high-precision NTC temperature sensing, ±1℃ accuracy, and multiple working modes including cooling, heating and ventilation. This WIFI cooling heating DC brushless Smart Thermostat is with 3-speed fan control, child lock, timing, temperature compensation and LCD display, it adopts flame‑retardant PC+ABS shell and standard 86-type installation, safe, stable and widely used in home and commercial HVAC control.
FEATURES:
- 2 pipe 1ch Heating or cooling single stage
- DC brushless RS485 modbus
- support WIFI app control
- Default voice control supports TUYA (Alexa, google assistant, contact us)
- LCD display with real-time temperature and status indication
- High-precision NTC thermistor with ±1℃ control accuracy
- 3-speed fan (low/medium/high) or 0~10v fan control for option (contact us)
- Timing function with network time sync (WiFi models)
- Child lock to prevent accidental mis-operation
- Adjustable temperature compensation from -9℃ to 9℃
- PC+ABS flame-retardant housing for safe and durable use
- Standard 86×86mm wall-mounted design, easy to install (customizable)
| Item | Specification |
| Temperature Sensor | NTC Thermistor |
| Control Accuracy | ±1°C |
| Temperature Setting Range | 5–35°C |
| Display Range | 0–50°C |
| Operating Environment Temperature | 0–45°C |
| Display | LCD |
| Operating Humidity | 5–95% RH (non-condensing) |
| Power Supply | AC 180–260V, 50/60Hz |
| Power Consumption | < 1W |
| Load Power | < 300W |
| Wiring Terminal | Suitable for 2×1.5mm² or 1×2.5mm² wires |
| Housing Material | PC + ABS Flame Retardant |
| Product Dimensions | 86×86×17mm (W×H×D) |
| Mounting Hole Distance | 60mm (Standard) |
